AGIE - AGIETRON INNOVATION 2CH-EDM-AGI-2002-00001

Name: AGIE AGIETRON INNOVATION 2
Brand: AGIE
SKU: CH-EDM-AGI-2002-00001
Price: 10450 GBP
Availability: InStock

£ 10,450

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used AGIE AGIETRON INNOVATION 2 For Sale | gindumac.com

Show in original language

This 3-axis AGIE AGIETRON INNOVATION 2 die-sinking EDM machine was manufactured in 2002. It features X/Y/Z travel of 350 x 250 x 350 mm, can handle workpieces up to 650 x 580 x 250 mm, and supports a maximum workpiece weight of 400 kg. Equipped with a 28-position rotary type electrode changer and a generator power of 72 A, this machine offers robust capabilities for precise die-sinking applications. Contact us for more information about this machine.

Overview

brand: AGIE
year: 2002
MODEL: AGIETRON INNOVATION 2
application type: EDM
Location: Switzerland
machine type: Die-Sinking EDM Machine

Technical Information - AGIE AGIETRON INNOVATION 2

General Data

Measurements width: 1855 mm
Measurements depth: 2689 mm
Measurements height: 2603 mm
Machine weight: 3000 kg

Main drive

Number of axis: 3

Movement

X-AXIS Movement: 350 mm
Y-AXIS Movement: 250 mm
Z-AXIS Movement: 350 mm

Workpiece

Workpiece weight: 400 kg

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Max. Workpiece dimensions: 650 x 580 x 250 mm
- - Table size: 650 x 450 mm
- - Electrode changer: 28-position rotary type
- - Max. Electrode weight: 50 kg
- - C-axis: 0-60 rpm
- - Generator power: 72 a

Extra information

- Machihne still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
