DOOSAN Puma TT1800SY

Photo Gallery

DOOSAN - Puma TT1800SYES-TUR-DOO-2006-00001

Sold

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
Doosan Puma TT1800SY

Show in original language

This Doosan TT1800SY Lathe was manufactured in the year 2006. It is equipped with a FANUC Series 18i-TB control unit. This 4 axis machine works with a spindle speed up to 5000 rpm and a turning diameter of 230 mm. It has C and Y axes, plus 2 spindles. This machine is in good condition and fully overhauled.

Overview

brand: DOOSAN
year: 2006
MODEL: Puma TT1800SY
application type: Turning
Location: Spain
machine type: Turn-Mill Centre
control unit brand: FANUC

Technical Information - DOOSAN Puma TT1800SY

General Data

Measurements width: 4018 MM
Measurements depth: 2162 MM
Measurements height: 2085 MM
Machine weight: 8800 KG

Control Unit

Model: Series 18i-tb
Brand: FANUC

Main drive

Number of spindles: 2
Spindle speed range: 5000 1/MIN
Number of axis: 4

Movement

Y-AXIS Movement: 100 mm
A-AXIS Movement: 770 mm

Workpiece

Workpiece drm: 230 mm

Tools

Slots in storage: 24 x 2
Max tool length: 20 mm
Type of tool holder: bmt

Media

Chip conveyor: Yes

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Distance between centres 750 mm
- - Max. Turning diameter 230 mm
- - C-axis; y-axis
- - X-axis movement: x1 165 mm / x2 190 mm
- - Z-axis movement: z1 700 mm / z1 720 mm
- - 2 3-jaw chucks; bar feeder interface
- - Sub-spindle
- - Fixed tool holders
- - Bar pitch diameter 65 mm
Qualitative Machine Benefits:
- - In good condition
- - Fully overhauled

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
