➤ Used EMAG VSC 250 | Vertical Lathe For Sale

Show in original language

This EMAG VSC 250 vertical turning machine was manufactured in 2014. It features a powerful main spindle drive with up to 28kW power at 40% duty cycle and a speed range of 0-4500 rpm. Equipped with a Siemens SINUMERIK 840Dsl control system and a robust 12-position EMAG flange turret, it ensures precise and efficient operations. Ideal for handling workpieces up to 6kg with its specialized hydraulic chuck. For more information about this vertical turning machine, please reach out to us.

Overview

brand: EMAG
year: 2014
MODEL: VSC 250
application type: Turning
Location: Poland
machine type: Vertical Turning Machine
control unit brand: SIEMENS

Technical Information - EMAG VSC 250

General Data

Measurements width: 1500 mm
Measurements depth: 3900 mm
Measurements height: 3200 mm
Machine weight: 7000 kg

Control Unit

Model: SINUMERIK 840Dsl
Brand: SIEMENS

Main drive

Spindle speed range: 4500 rpm 1/MIN
Spindle motor power: 18kW at 100% duty cycle, 28kW at 40% duty cycle
Tool taper: DIN 55026 - A6
Number of axis: 2

Movement

X-AXIS Movement: 745mm
X-AXIS Rapid traverse: 60m/min
Z-AXIS Movement: 300mm
Z-AXIS Rapid traverse: 30m/min

Media

Chip conveyor: Yes
Internal cooling: Yes

Additional Equipment

- Coolant tank capacity: 360 liters

Additional Information

Machine Benefits

Technical Machine Benefits:
- - High working accuracy, rapid traverse speeds, high maximum speed of driven tools
- - Machine from single shift operation
- - Maximum room temperature: up to 30°c
- - Maximum humidity: 50%
- - Sound pressure level: 78db(a)

Extra information

- Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
