SUMITOMO SHI DEMAG - IntElect 160/520-340 smartDE-INJ-SUM-2013-00003

Additional Equipment

• - Sepro Robot SDR 11

Additional Information

Machine Benefits

• Technical Machine Benefits:
  • - Clamping unit: 160 / locking force: 1760 kn / opening stroke max: 495 mm / mould installation height, min: 275 mm / mould installation height, max: 585 mm
  • - Platen distance, max: 1080 mm / mould mounting platens (h x v): 760 x 785 mm / clear column distance (h x v): 520 x 520 mm
  • - Ejector travel: 125 mm / ejector force: 35 kn
  • - Injection unit: 340 / screw diameter: 35 mm / l/d ratio: 20 / injection flow (ps) without accumulator: 288 cm³/s
  • - Metering stroke: 162 mm / nozzle stroke, max: 350 mm / nozzle immersion depth (svo): 20 mm / nozzle contact pressure: 30 kn
  • - Material hopper capacity: 35 l / injection speed, max. , standard: 300 mm/s / injection speed, max. , increased: 500 mm/s
  • - Net weight without oil filling: 7300 kg

Payment Terms

• Payment in advance

• Asset Financing
